Panel
Weight
Dimension
Wave Tile
10 lbs./box
19.69" x 19.69" x 1.97"
All specs refer to singular products and not multiples unless specified. Due to the nature of the material, cutting and fabrication process, minor dimensional variances may occur. Custom options available upon request.
Acoustic Data
NRC: 0.55
Fire Rating
ASTM E84 Class A
Material
Tiles: 100% PET (27% post-consumer recycled). Clips: Polycarbonate resin
VOC Emissions
CDPH (CA 01350) Compliant TVOC: <0.5 mg/m3 Ecospecifier GreenTag Compliant TVOC: 0.015 mg/m2/hr (ASTM D5116)
Installation
Each box includes 9 tiles and a bag of mixed clips appropriate for a 3 tile by 3 tile installation. Other layouts will require extra clips, available through Kirei. See the Wave Tiles Installation Guide for more information.
