Panel
Weight
Dimension
Barcode Tile
8 lbs./box
15.5 in. x 7.75 in. x 0.94 in.
All specs refer to singular products and not multiples unless specified. Due to the nature of the material, cutting and fabrication process, minor dimensional variances may occur. Custom options available upon request.
Acoustic Data
NRC: 0.60
Fire Rating
ASTM E84 Class A
Material
100% PET (60% post-consumer recycled)
VOC Emissions
CDPH (CA 01350) Compliant TVOC: <0.5 mg/m3 Ecospecifier GreenTag Compliant TVOC: 0.015 mg/m2/hr (ASTM D5116)
Installation
Mount to wall or ceiling using standard construction adhesives. For more information, see the Barcode Tile Installation Guide.
