Panel
Weight
Dimension
Subway
16.5 lbs
46"L x 108"H x 0.47"D
All specs refer to singular products and not multiples unless specified. Due to the nature of the material, cutting and fabrication process, minor dimensional variances may occur. Custom options available upon request. EchoLine is sold individually and ships flat.
Acoustic Data
NRC: 0.30 - 0.40 determined by style and installation
Fire Rating
ASTM E84 Class A
Material
100% PET felt made with at least 60% post-consumer recycled content
VOC Emissions
CDPH (CA 01350) Compliant TVOC: <0.5 mg/m3 Ecospecifier GreenTag Compliant TVOC: 0.015 mg/m2/hr (ASTM D5116)
Installation
Subway Panels come in 46” x 108” panels that fit walls up to 9' in height without horizontal seams. Panels can be edge-matched for large multi-panel walls and are installed using construction adhesive or mechanical fasteners.
